Feature
Reliable way to connect the tube.
Working with high pressure.
Suitable for different tube material.
Specification
Fluid Admitted | Air, Water, Steam |
Max Working Pressure | 2MPa | 290psi |
Working Temperature | -20°C—120°C | -4°F—248°F |
Body | Nickel Plated Brass |
Applicable Pipe | PU/PA/FEP/PFA |
| Metric Tube ØD | ||||
| 4mm | 6mm | 8mm | 10mm | 12mm |
| Thread Standard and Type | |||||||
| R, PT, BSPT — 55° Taper Pipe Thread | BSPP, G-55° Parallel Pipe Thread | ||||||
| R1/8 | R1/4 | R3/8 | R1/2 | G1/8 | G1/4 | G3/8 | G1/2 |
Model No. | Tube ΦD | Thread (PT, R, BSPT) |
RPB 4/2-M5 | 4/2mm | M5 |
RPB 4/2-M6 | 4/2mm | M6 |
RPB 4/2-01 | 4/2mm | R3/8 |
RPB 6/4-M5 | 6/4mm | M5 |
RPB 6/4-M6 | 6/4mm | M6 |
RPB 6/4-01 | 6/4mm | R1/8 |
RPB 6/4-02 | 6/4mm | R1/4 |
RPB 6/4-03 | 6/4mm | R3/8 |
RPB 8/6-01 | 8/6mm | R1/8 |
RPB 8/6-02 | 8/6mm | R1/4 |
RPB 8/6-03 | 8/6mm | R3/8 |
RPB 10/8-01 | 10/8mm | R1/8 |
RPB 10/8-02 | 10/8mm | R1/4 |
RPB 10/8-03 | 10/8mm | R3/8 |
RPB 10/8-04 | 10/8mm | R1/2 |
RPB 12/10-02 | 12/10mm | R1/4 |
RPB 12/10-03 | 12/10mm | R3/8 |
RPB 12/10-04 | 12/10mm | R1/2 |
